Product Description
The all new Status Pro LED lighting system. Utilizing energy efficient LED technology to give real-time status of the spa.
Specifications:
- Dimensions: 95mm (L) x 30mm (W) x 120mm (D)
- Compatible With: The BP Series by Balboa such as the BP2100, BP601 and BP100.
- Connections: 4 black plastic pins in a grid formation
- Energy efficient, long lasting LED Technology
- Green Light: Spa Pack is operational
- Blue Light: Spa Pack is operational but information message displayed (no error code)
- Red Light: Warning messages or faults present
- Red Light (Flashing): Severe warning messages or faults present
Notes:
Install somewhere in a dry place within the cabinet of the Hot Tub. Connect either directly into the control box or use a splitter to use in conjunction with the topside panel.
This device works only with licensed Balboa products, use with any other device is not recommended and will instantly void warranty and could also cause damage to existing software.
